一、Instrument Overview：

The KODIN 6A-UT intelligent connected ultrasonic flaw detector is an intelligent flaw detection terminal developed by Kedian Instrument based on the Android system.
This instrument has wireless communication function, which can achieve remote interaction and cloud detection; The combination of IPS high-definition color screen touch and physical buttons makes human-computer interaction more convenient;
We can provide specialized customized services and wireless upgrades; The casing adopts waterproof, dustproof, and anti drop design, which can adapt to various complex industrial sites.

二、Technical Specifications：

Working mode: single crystal, twin crystal;
Probe type: straight probe, oblique probe;
Coordinate system: acoustic path (S), depth (H), horizontal distance (L);
Operating frequency: 0.5-20MHz;
Sound path: 10-5000mm;
Translation: 0-500mm;
Gain: 0-110dB, step values: 0.1dB, 1dB, 2dB, or 6dB;
Sound speed: 1000-9999m/s;
Waveform suppression: 0-80%;
Pulse type: negative square wave pulse;
Pulse width: 100-300ns, available in 11 levels, with a pulse width interval of 20ns per level;
Matching resistance: available in two levels: 200 Ω and 500 Ω;
Emission voltage: 200V and 400V are available for selection;
Automatic wave height: 20-80%;
Surface compensation: 0-10dB;
Detection methods: positive detection, negative detection, full detection, RF;
Alarm function: gate alarm, curve alarm;
Curve type: angle probe: DAC curve; Direct probe: AVG curve and DAC curve;
Wave amplitude reading: wave amplitude percentage, relative gate equivalent, relative curve equivalent, and display of diameter value;
Vertical linear error: ≤ 2.8%;
Horizontal linear error: ≤ 0.1%;
Sensitivity margin: ≥ 48dB (depth 200- φ 2 flat bottom hole, 2.5P20);
Resolution: ≥ 36dB;
Dynamic range:>32dB;
Electrical noise level:<10%;
Probe blind spot: ＜ 6mm (straight probe 2.5P20);
Working environment: Temperature: -10 ℃ -40 ℃, Humidity: 20% -90% RH;
Power supply: Built in DC: 5000mAh/7.6V lithium-ion battery; External AC: 220V/50Hz AC+adapter (10V/2A);
Screen display: 6.0-inch IPS color LCD screen, 720 * 1280 pixels;
Storage method: 16GB eMMC+2GB LPDDR3, expandable to 32GB TF card;
CPU: 64 bit quad core 1.2GHz;
Operating system: Android;
Host size: 216mm (L) * 98mm (W) * 28mm (H);
Host weight: approximately 570g.

三、Site of use：

四、Standard product packing list：

1 intelligent connected ultrasonic flaw detector 6A-UT 1 set
2 sheaths 6A-UT 1 piece
3 power adapters 10V, 2A 1
4 straight probes 2.5P20 1 piece
5 oblique probes 2.5P8 * 12K2.5 1 piece
6-pin universal type 1
7 Q9 probe wires 1500mm 2 pieces
8 suitcases 6A-UT 1 piece
9 User Manual 6A-UT 1 copy
10 copies of certificate 6A-UT
11 Factory Inspection Report 6A-UT 1 copy
12 LCD protective film 6A-UT 1 part

Optional accessories:
1 test block
2 probes
3 Coupling agents
